2023 Ford Explorer Service and Workshop Manual PDF

Are you a Ford Explorer owner looking to keep your SUV in top condition?

The 2023 Ford Explorer factory service manual has got you covered, with everything you need to keep your SUV in top shape. Get into wiring diagrams, troubleshooting guides, and specs to ensure every aspect of your Ford Explorer is well taken care of.

Specifications of 2023 Ford Explorer

The Ford Explorer 2023 comes in 5 models: Base, XLT, Limited, ST and Platinum. Each has its own features and specs.

Engine Options:

• The base has a 2.3L EcoBoost I-4 engine.
• It also has a 3.0L EcoBoost V6 engine.
• For hybrids, there’s a 3.3L Hybrid V6 engine.

Trim Levels:

• Explorer: Base model with 8 inch touchscreen, Apple CarPlay, and Android Auto.
• XLT: Adds comfort with cloth upholstery, heated front seats and second-row captain’s chairs.
• Limited: Leather seating, premium audio and more advanced safety features.
• ST: Sporty with unique grille, sport-tuned suspension and turbocharged V6.
• Platinum: Luxury with high-end materials, twin-panel moonroof and adaptive headlights.

Interior:

• Up to 7 passengers can sit comfortably.
• The second and third row fold flat for cargo space.

Technology:

• SYNC 3 standard on most trims.
• 12.3 inch digital instrument cluster available.
• USB ports for all passengers.

Safety Features:

• Co-Pilot360 suite standard with automatic emergency braking, blind-spot monitoring and lane-keeping assist.
• Adaptive cruise control and parking assist are available.

Fuel Efficiency:

• 2.3L around 24 combined.
• Hybrid is more efficient in city driving.

The 2023 Ford Explorer offers a mix of power, comfort, and technology across its various models and trims, making it a versatile choice for any driver.

What Changes Have Been Made to the 2023 Model Explorer?

The 2023 Explorer has some changes from the 2022 model. Here’s a quick rundown:

Design Changes:

• New front grille design and updated LED headlights.
• New wheel options.

Interior Updates:

• Upgraded cabin materials.
• 10.1 inch touchscreen in higher trims.
• Better sound insulation.

Technology:

• SYNC 4 replaces SYNC 3 with faster response and better graphics.
• Wireless Apple CarPlay and Android Auto standard.
• More USB ports.

Safety:

• Co-Pilot360 suite now includes Intersection Assist and Reverse Brake Assist.
• Traffic Sign Recognition and 360 camera available.

Performance:

• ST trim’s sport suspension refined for better handling.
• Hybrid has better battery efficiency, slightly more fuel economy.

Trim Level Changes:

• Some features that were optional in 2022 are now standard on 2023 XLT and Limited.
• New interior colors available on all trims.

What Instructions are Included in the Factory Repair Manual?

The Ford Explorer repair manual has all the instructions you need to maintain and repair your vehicle. From basic maintenance to complex repairs, your 2023 Explorer will be running like new. Here’s what’s included:

• Brake System Analysis
• Engine and Transmission Maintenance
• Radiator Maintenance and Replacement
• Fuel System Analysis
• Troubleshooting Manual
• Suspension Tuning
• Turbocharger and Supercharger Maintenance
• Lighting Services
• Starter and Alternator Maintenance
• Exhaust Maintenance
• Electrical Testing
• Interior and Exterior Vehicle Upkeep
• Battery Care
• Oil Change Procedures
• Timing Belt Care
• Steering System Maintenance
• Air Conditioning and Heating Services
• Wheel and Tire Alignment
